| Fuse No. | Fuse Rating | Fuse Colour | Function |
|---|
| 1 | 25A | Neutral | Engine | | 2 | 25A | Neutral | Windscreen wipers | | 3 | 20A | Yellow | Electric windows L&R | | 4 | 25A | Neutral | Interior fan | | 5 | 10A | Red | Front fog lamps | | 6 | 7.5A | Brown | Right parking light, instrument lighting, terminal 58R | | 7 | 7.5A | Brown | Left parking light | | 8 | 25A | Neutral | Engine | | 9 | 7.5A | Brown | Engine | | 10 | 15A | Blue | Engine | | 11 | 25A | Neutral | ESP | | 12 | 10A | Red | Switches strip, OBD, indicators, rear fogs,
transmission control unit | | 13 | - | - | - | | 14 | 15A | Blue | Charge air cooler, air conditioning compressor | | 15 | 15A | Blue | Audio, subwoofer, interior light | | 16 | 15A | Blue | Fuel pump | | 17 | 15A | Blue | Rear Wiper (coupé only) | | 18 | 10A | Red | ESP, EPS, airbag, instrument panel | | 19 | 7.5A | Brown | Motor control unit | | 20 | 10A | Red | Aircon, electric mirrors, washer pump,
audio, heated seats, SE drive switch. | | 21 | 15A | Blue | Power Socket, cigarette lighter | | 22 | 7.5A | Brown | Low Beam L | | 23 | 7.5A | Brown | Low Beam R | | 24 | 15A | Blue | Brake lamps, rain/light sensor, combination switch L | | 25 | 7.5A | Brown | High Beam R | | 26 | 7.5A | Brown | High Beam L | | 27 | 7.5A | Brown | ECU | | 28 | 40A | Orange | Rear window heater (coupé) / engine fan | | 29 | 30A | Green | Softop drive unit (cabrio) | | 30 | 40A | Orange | Relay for auto gearbox / SE drive unit | | 31 | 20A | Yellow | Horn, central locking, doors | | 32 | - | - | - | | 33 | 50A | Red | Ignition | | 34 | 40A | Orange | ESP Pump | | 35 | 30A | Green | EPS (Power Steering) | | R1 | 5A | Brown | Spare circuit - switched live (mirror heating) | | R2 | - | - | Spare circuit - switched live | | R3 | - | - | Spare circuit - switched live | | R4 | - | - | Spare circuit - switched live | | R5 | - | - | Spare circuit - permanent live | | R6 | - | - | Spare circuit - permanent live | | R7 | - | - | Spare circuit - permanent live | | R8 | - | - | Spare circuit - permanent live | | R9 | 20A | Yellow | Spare circuit - permanent live (heated seats) |
Fuses 32-35 can be found on the rear of this SAM unit.
Expansion slots R1-R4 are switched with the ignition.
Expansion slots R5-R9 are constant live slots.
|
