| Thermostat change |
|
|
A faulty Thermostat can be diagnosed by 2 very distinct issues.
You'll see the thermostat located here:
Remove the vacuum pipe from the FPR, and pull the breather pipe out of the way.
Unplug the temperature sensor connector.
Remove the hose clips. Note, the standard smart clips are single use and are crimped on.
Now remove the 2x torx bolts (using an E12 bit) holding the thermostat onto the face of the cylinder head.
Now pull all the water transfer pipes off (remember of course they will be full of water!)
Now remove the old thermostat. You may need to rotate it a bit to be able to remove it easily.
Clean the mounting face on the block.
Feed in the replacement thermostat, and connect the pipes! You will struggle to tighten the hose clips if you leave this stage to later.
Now seat the thermostat onto the block face. It should locate with the seal - use one of the bolts to locate if it helps, then tighten down.
Remember to reconnect the sensor.
Reconnect the breather hose and vacuum pipe.
Finally, remember to raise the engine back up again!
|
